Hello Everyone,
Subscribe for upcoming series to learn Mastercam software. These videos are available in both Hindi and English for your convenience.
Mastercam Training video made to those working in CNC ,CAD /CAM area.
Common Parameters: Mill/Router
Use the Edit Common Parameters, Mill/Router dialog box to set values for one or more toolpath parameters for several operations at the same time.
Clearance
Sets the height at which the tool moves to and from the part. Select the checkbox to activate the clearance height
Retract
Sets the height that the tool moves up to before the next tool pass. Select the checkbox to activate the retract plane
Feed plane
Sets the height that the tool rapids to before changing to the plunge rate to enter the part. The tool also moves to this height between operations if you do not enter both the clearance height and the retract height.
Top of stock
Sets the height of the material in the Z axis. Many other toolpath parameters are measured from this position in incremental mode, such as clearance, retract, and feed planes.
Depth
Determines the final machining depth and the lowest depth that the tool descends into the stock. The default depth is the depth of the first chain selected.
Rapid retract
Select to retract from the part at the rapid rate set at the machine tool.
Force tool change
When successive operations use the same tool, this option writes a tool change code (1002) to the NCI file instead of a null tool change (1000) to trigger a event between the two operations.
Coolant
Click the button to open the Coolant dialog box where you can select coolant options. Misc values
Sets the values of custom integer and/or real variables that have been defined for this machine. Click on the button to review or change the values.
Planes
Select to set or change any of the following:
the tool plane (Tplane) or work coordinate system used for the operation
the Tplane or WCS origin
the work offset associated with this operation.
Home position
Sets the position on the machine tool where the tool returns for tool changes and at the end of the NC program. NC name
Select to open the Enter new NC name dialog box where you can change the name of the resulting NC file.
Reference point
A reference point is a location that the tool moves to between the home position and the start of the toolpath (approach point), and another location that the tool moves to at the end of the toolpath before returning to the home position (retract point).
Head number
Sets which spindle or head is used on a machine tool with multiple spindles or heads. A setting of -1 means that the Head number parameter is not used
Feed rate
Sets the rate--inches per minute or millimeters per minute--at which the tool moves through the part. In 2-axis machining (except drilling), the feed rate only applies to tool movements in the X and Y directions Mastercam calculates a default value according to the Machine group properties, but you can override this by typing in a new value.
Plunge rate
Sets the feed rate Mastercam uses when plunging into the part. Typically, this applies to tool movements in the negative Z direction only.
Length offset
Can be used by the post processor in place of the tool number to select the length offset register in the control.
Diameter offset
Can be used by the post processor in place of the tool number to select the diameter offset register in the control.
Retract rate
Sets the feed rate Mastercam uses when pulling away from the part. Typically, this applies to tool movements in the positive Z direction only.
Spindle speed
Determines the rotation speed of the spindle in revolutions per minute (RPM). Mastercam calculates a default value according to the machine group properties
Spindle direction
Determines the rotation direction of the spindle. Select CW or CCW.
Tool selection window
Chose the checkbox to activate the Tool selection window, which displays the tools used in the selected operations.).
Tool filter
Select the checkbox to activate the tool filter. The only tools that are displayed in the tool list window are those that meet the filter criteria.
