This video instructs the user how to replace the HMI touch screen.

1. Unplug the unit from the outlet to power down before performing electrical work.

2. Remove the 6 screws holding the front bezel in place.

3. Flip the bezel up and secure with one of the mounting screws.

4. Disconnect the electrical connectors:
Green electrical connector, Green PLC connection, USB connection, and USB programming connection.

5. Remove the HMI by loosening the brackets on either side while holding the HMI to prevent it from falling.

6. Insert new HMI in correct orientation and secure with mounting brackets.

7. Reattach the electrical connections removed in step 4.

8. Flip the bezel back over and secure with the 6 mounting screws.

9. Plug in the unit and power up the ensure the new screen functions properly.
