Heavy Duty Grip Strut safety grating Non-serrated surface Slip resistance​



Grip Strut Plank Grating also named diamond grip plank grading, grip strut safety grating. Our this perforated plank grating has serrated surface, provide a safer surface than many other grating products. It helps eliminate costly accidents, which reduces insurance costs and lost production. The open diamond pattern allows most debris and dirt to drain. Grip Strut Plank Grating is available in serrated and smooth diamond patterns, create non-slip walkways and stair treads. Material be Pre-Galvanized,Plain Steel,Stainless Steel and Aluminum Alloy.



Custom Design:

All Guorun safety gratings are also available as flat blanks without folded edges.

In that case, the maximum embossed field width must not be greater than 750 mm for diamond forms.

For manufacturing reasons, these flat cuts have a slightly curved finish.

Gratings with other dimensions (H/W/L) than those mentioned above can also be produced.

Gratings with unperforated edges or surfaces on one or both front surfaces are also available.

We can also be supplied with ø 5-mm drain holes.

Please contact us for further technical questions.



Materials of grip strut plank grating, stairs trends grating

Pre-Galvanized Steel (ASTM A-924-G90): 12 Gauge or 14 Gauge.
Hot Rolled Steel: 12 Gauge or 14 Gauge.
Aluminum Alloy 5052H32: 0.080" Thick or .100" Thick .
Stainless Steel Type 304 or Type 316: 16 Gauge.


General Specification
Material Grade Pre-Galvanized Steel
Hot Rolled Pickled and Oiled (HRPO) steel
Aluminum Alloy 5052
Stainless Steel 304, Stainless Steel 316
Material Gauge 9Guage, 10Guage, 11Guage, 12Guage, 13Guage,
Available Patterns Standard Serrated, Non-serrated, Heavy duty
Widths and holes number 2 Diamond holes for 4-3/4"width
3 Diamond holes for 7" width
4 Diamond holes of 9-1/2" width
5 Diamond holes of 11-3/4" width
6 Diamond holes of 14-3/4" width
7 Diamond holes of 17" width
9 Diamond holes of 21-1/2" width
10 Diamond holes of 24" width
Channel Depth 1-1/2, 2, 2-1/2, 3" or customized
Channel Length 6',8', 10', 12', or customized
Loading capacity To check with our sales or engineers for Loading capacity table list
Slip resistance complies with Federal Specification RR-G-1602D stan
