Скачать или смотреть Welding fixture tilt table full || Download free 3D models

Kuka K6 robot on the trolly and the Naboshi center robot load the frame pieces into the fixture. The when the nest limits are all made the clamps set. When the clamped positions are confirmed the fixture tilts towards the 4 Kuka K-16 robot welders on the opposite side of the fixture. Tilts back Naboshi robot removes fully welded frame and drops onto assy line pallet. Cycle time 1:18

Software: STEP / IGES, Rendering
Categories: Automotive, Industrial design, Machine design
