Cerium Oxide Spray Dryer，YPG Pressure Atomizing Granulating Dryer
Http://www.ycdrying.com E-mail:[email protected]
Welcome to Changzhou Yongchang Granulating Drying Equipment Co., Ltd.

Descriptions
This set is an apparatus that can finish drying and granulating at the same time.The
needed ball granule with certain size and ratio can be got in accordance with requirements
of process to adjust pressure，flow，and size of atomizing hole．
The working process of this set is as foIlows：the Iiquid of raw material is pumped in
through diaphram pump.The liquid of raw materiaI be atomized into tiny droplets.Then it
gathers with hot air and faIl off.Most parts of powder material wilI be collected through the
outlet of discharge at the bosom.The wasted air and fine powder wilI be collected through
collector at the botton of cyclone．At the outlet it can also be equipped with two grades of
duster．Its ratio of recovery wilI be 96—98％．
The tower body,pipes and separator of set where wilI contact with raw material are
made of SUS304.There is enough layer of heat preservation between inner and outer case
of tower body.The filled materiaI is fine glass cotton.The tower body is also equipped with
observation door,sight glass.Iamp-house and controI meters and instruments that is controlled
and displayed through electric controI panel．
The heat source of this set may be steam or electric heater.Its features are convenient in operation，quick in start，compact，clean
hot air and so on．Moreover being installed controI and regulating device inside eletctric controI cabinet．the inlet temperature can be controlled
through stepless regulation．The steam．coaI fueI or oiI fuel can be applied to the place where has not electricity．It can replace electric heating
partially or fully．The factory can provide different heating way in accordance with the practicaI conditions of customer．
