1 piece used Horizontal- table type boring machine in avery good condition
Make: TOS VARNSDORF Model: WH63/80
Year of manufacturing: 1976 Machine- No: 512566

Technical Datan:

Diameter of the spindle: 63 mm
Range of speeds: 18- 1.800 U/min
Nose taper: MK4
Measuring system: Optical
Travels:
X- Axis (Table): 1.000 mm
Y- Axis (Table): 1.000 mm
Z- Axis (Spindle head): 710 mm
W- Axis (Spindel): 500 mm
Rotary table: 800- 890 mm
Capacity of the rotary table: 2.000 kg Capacity of the motor: 7,3 kW
Power supply: 380 V
Dimensions of the table (LxWxH): 4.200 x 2.200 x 2.430 mm

Equipped with:
Tailstock
Face plate
Several tools and holders
Machine- Documentation
