Скачать или смотреть Needle Flame Test Setup | IEC 60695-11-5 | Fire Hazard Testing Equipment

#NeedleFlameTest, #NeedleFlameTestSetup, #IEC60695115, #FireHazardTest

This video showcases the Needle Flame Test Setup manufactured by CK INSTO Pvt. Ltd., designed to evaluate the flammability and fire resistance of electrical and electronic components when exposed to a small ignition source.

The Needle Flame Test simulates real-world fire hazards that may occur due to faults, short circuits, or overloads in electrical products. It is a critical safety test used globally to determine whether a material self-extinguishes or continues to burn, helping manufacturers ensure compliance with international fire safety regulations

Needle Flame Test Apparatus

✅ Key Features & Specifications

• Horizontal & Vertical test orientation
• 0.5 cubic meter MS powder-coated test chamber
• Glass viewing window with exhaust fan
• Needle burner with 0.5 mm diameter
• Adjustable burner stand at 0°, 20° & 45°
• Motorized burner movement
• Flame height: 12 mm ± 1 mm
• K-Type thermocouple (0.5 mm dia.) with copper block
• Flame temperature rise from 100°C to 700°C within 23.5 ± 1 sec
• Height-adjustable sample mounting stand
• HMI-based operation for safe and precise testing

🔬 Test Principle

A needle-shaped flame is applied to the test specimen for a specified duration (10, 20, or 30 seconds). The behavior of the material is observed to check ignition, flame spread, and self-extinguishing characteristics.

Pass / Fail Criteria:
✔ Pass – Sample self-extinguishes within 30 seconds and does not ignite surrounding materials
✖ Fail – Flame persists beyond 30 seconds or spreads to nearby objects

Needle Flame Test Apparatus

🏭 Applications

• Electrical & electronic components
• Plugs, sockets, switches, fuse holders
• Automotive wiring & battery housings
• Household appliances
• Lighting equipment & enclosures
• Building & construction electrical accessories

📘 Standards & Compliance

This Needle Flame Test Setup complies with and supports testing as per:

• IEC 60695-11-5 – Needle flame fire hazard test
• UL 746A – Polymer material flammability
• EN 60695 – Fire hazard testing standards

Needle Flame Test Apparatus

📍 Manufacturer: CK INSTO Pvt. Ltd.
🌐 Website: www.ckinsto.com
📧 Email: [email protected]
