Welcome to Can CAD Channel! In today's video, I’ll walk through some essential tips for drawing a floor plan in meters using AutoCAD. You'll learn how to:

Use the OFFSET command to create inner and outer wall thickness (100mm and 150mm/200mm).
Separate lines with the EXPLODE command.
Draw and connect roof lines with the FILLET command (600mm and 450mm).
Apply a dash-space linetype and adjust it with the LTSC command.
Finish up by drawing kitchen lines with the OFFSET command.
If you want to dive deeper into AutoCAD's powerful commands like OFFSET, JOIN, EXPLODE, FILLET, and LTSC, make sure to check out the links in the description. Don’t forget to subscribe for more helpful tutorials!
