PU edge rockwool sandwich panel production line
Rockwool sandwich panels are versatile and find application in building construction, cold storage, industrial facilities, cleanrooms, transportation, and automotive sectors.

Their thermal insulation, fire resistance, acoustic properties, durability, and ease of installation make them a preferred choice in various industries.


The composition of a rockwool sandwich panel production line typically includes the following components:

1. Uncoiler: This machine is used to unwind and feed the metal coils that will form the outer layers of the sandwich panel.

2. Roll forming machine: The roll forming machine shapes the metal coils into the desired profile, typically corrugated or flat,which will serve as the outer layers of the sandwich panel.

3. Glue application system: This system applies adhesive or glue onto the metal coils to ensure proper bonding with the rockwool core.

4. Rockwool insulation material: The rockwool, also known as mineral wool, is a key component of the sandwich panel.
It is typically supplied in the form of rolls or sheets and is placed between the outer metal layers.

5. Pressing machine: The pressing machine compresses the metal layers and the rockwool core together, ensuring a strong and uniform bond.

6. Cutting machine: Once the sandwich panel is formed, a cutting machine is used to trim it to the desired length.

7. Stacking and packaging system: The finished sandwich panels are stacked and packaged for storage or transportation.

It's important to note that the specific composition and configuration of a rockwool sandwich panel production line may vary
depending on the manufacturer and the desired specifications of the panels.
Normally the whole line only needs 8 operators to run.

The conveying belt length could be customized!
It's 6 meteres/track(section),such as 18 meter,24 meters...
It's depends on client's need.
