Playing around with the RING SM from AJH Synth. This is a hugely useful module, combining a 3-way all-analogue Ring Modulator, a -1 and -2 octave sub-bass generator, and 5-channel Moog CP-3 based mixer.
This is a real ring mod, as opposed to the more common, simpler and cheaper circuits found in many synths, such as the Odyssey, which often used CMOS chips to mimic the same behaviour. The authentic vintage circuit recreated in the RING SM is based on the Ring Mod of the EMS Synthi/VCS3, and has a hugely thick, rich tone.
The Sub Bass generator derives shaped square waves at 1 or 2 octaves below the pitch on an incoming VCO. This shaped squares are slightly curved at the edges, almost a cross between a square and a sine wave, which produces a much better balance of harmonic content and warmth/fatness than the common, purely square or sine sub basses found on most synths and modules, resulting in thicker yet more musical sub-octaves. Additionally, the 'Double' feature can generate an octave above the incoming triangle or sine wave.
The CP-3 mixers saturates as you'd expect from this classic vintage design, with soft clipping, and a boosted gain level on input channel 5.

All modules are available in Vintage black, or silver (aluminium/aluminium) panels as seen here in this beautiful clear acrylic case by Casa Modular:
https://reverb.com/uk/shop/casamodular
https://www.etsy.com/shop/CasaModular

Video & Performance by ‪@DreamsOfWires‬

Sequencer is the A-115-2 Mini Analog Sequencer by @DoepferMusikelektronikGmbH

RING SM User Guide Pt1:    • Ring SM User Guide - The AJH Synth Audio/C...
MATRIX VCF & CV Presets:    • MATRIX VCF & Voltage Control - Creating pr...
Melody & Probability Jam:    • Melody & Probability - #eurorack  Session ...

The AJH SYNTH Eurorack modular range consists of high-end modules, all hand-made in the UK, most of which are based on classic, vintage designs, authentically recreating the circuitry of much sought-after analogue instruments and technologies of the past, whilst greatly expanding them, and bringing them to modern Eurorack levels of convenience, limitless flexibility, and reliability.
Official website page: https://ajhsynth.com

Check out the AJH Synth playlists for module 'User Guides', and 'Patch of The Week' videos, which will be either performances or 'how to' guides, detailing functions/methods, and a range of sounds, some familiar, some less so, containing a patch sheet at the end to show you how to construct it for yourself.
