Скачать или смотреть 06 - Symmetry and Collinear - Geometric & Dimensional Constraints 101 - Dynamic Blocks

Learn how to build symmetrical, flexible geometry in AutoCAD using Symmetric, Coincident, and Collinear constraints, all wrapped into a practical, project-based example.

🔗 Download the extra learning materials:   / felttipfaerie

0:21 – Expected Knowledge
0:36 – What You Will Learn
0:48 – Lesson Starts

In this video you will learn:
• How to mirror geometry using the Symmetric constraint
• How Coincident constraints keep complex geometry connected
• How to use the Collinear constraint to align moving parts
• How dimensional constraints control overall shape and proportion
• How to build a project-based dynamic block with multiple moving elements

This lesson is part of my Geometric & Dimensional Constraints 101 series, where I show how multiple constraints work together to create clean, adjustable, and well-structured dynamic blocks.

Subscribe so you don’t miss the rest of the Geometric & Dimensional Constraints lessons.
