2013 Okamoto Grind-X ACC42SAiQ CNC Surface Grinder – High Precision, Very Good Condition

Now available for immediate sale: the 2013 Okamoto Grind-X ACC42SAiQ, a CNC-controlled surface grinder built for high-precision applications. This machine offers outstanding rigidity and control, with full automation features for maximum efficiency in toolrooms and production environments alike.

This model features a 400 x 200mm SAV magnetic chuck, automatic grinding wheel dresser, and a Daikin inverter chiller to ensure consistent cooling and precision during long cycles. Maintained in excellent condition, this grinder is an ideal solution for achieving fine surface finishes and micron-level tolerances.

🔧 Technical Specifications:
Table Size: 500 x 200mm
Max Table Travel: 510 x 230mm
Magnetic Chuck: 400 x 200 x 70mm
Max Workpiece Weight: 120kg
Table Feed Range: 100 - 20,000mm/min
Grinding Head Infeed (Rough): 0.001 - 0.03mm
Grinding Head Infeed (Fine): 0.0001 - 0.01mm
Grinding Wheel Speed: 1000 - 3600rpm
Grinding Wheel Dimensions: 205mm dia, 6–25mm thick, 31.75mm bore
Vertical Rapid Feed: 0 - 1000mm/min
Spark-Outs: Adjustable 0 – 99 times
Spindle Motor: AC 2.2kW
Power Requirement: 11kVA

🧰 Included Equipment:
Automatic grinding wheel dresser
400 x 200mm SAV magnetic chuck
Paper band coolant filtration system
Daikin inverter chiller unit

📐 Machine Dimensions & Weight:
Dimensions: 2400 x 2840 x 2247mm
Weight: 2000kg

🚀 Highlights:
CNC control with ultra-fine resolution
Perfect for toolroom and batch production
Fully equipped with filtration and cooling
Maintained to a high standard – excellent condition
Precision accuracy for surface grinding at scale
