Скачать или смотреть How Many Stepper Motor Sizes Are There?💭

In this video, we take a closer look at the full range of Hybrid Stepper Motors from Motion Control Products. Whether you’re working on compact applications or high-torque solutions, our motors are designed to meet diverse motion control needs.

We cover all available NEMA frame sizes from NEMA 8 to NEMA 42—highlighting step angles, output shaft options, torque specifications, and integration possibilities such as encoders and gearboxes.

𝗪𝗵𝗮𝘁 𝘆𝗼𝘂’𝗹𝗹 𝗹𝗲𝗮𝗿𝗻 𝗶𝗻 𝘁𝗵𝗶𝘀 𝘃𝗶𝗱𝗲𝗼! 🤩
NEMA 8 (20mm frame) – up to 0.03Nm torque
NEMA 11 (28mm frame) – up to 0.12Nm torque
NEMA 17 (42mm frame) – up to 0.7Nm torque
NEMA 23 (57/60mm frame) – up to 4Nm torque
NEMA 34 (86mm frame) – up to 12Nm torque
NEMA 42 (110mm frame) – up to 33Nm torque

𝗖𝗼𝗻𝘁𝗮𝗰𝘁 𝘂𝘀!📞
Website:https://motioncontrolproducts.com/ele...
Email: [email protected]
Phone: +44 (0)1202 599922

Don’t forget to like, subscribe, and click the bell icon to stay updated with our weekly motion control videos! ❤️

𝗬𝗼𝘂𝗧𝘂𝗯𝗲 𝗖𝗵𝗮𝗽𝘁𝗲𝗿𝘀 📄
0:00 – Introduction
0:35 – NEMA 8 Stepper Motors
1:05 – NEMA 11 Stepper Motors
1:35 – NEMA 17 Stepper Motors
2:05 – NEMA 23 Stepper Motors
2:35 – NEMA 34 Stepper Motors
3:05 – NEMA 42 Stepper Motors
3:40 – Outro & Contact Information

#StepperMotor #MotionControl #NEMA #HybridStepper #Engineering
