In this project, the heat transfer process in brake disks is simulated, and the simulation results have been investigated using ANSYS Fluent software.
Disks are one of the most widely used components in the industry. The study of the disks’ performance and their rotation’s effect on each other has always been considered by design engineers in mechanics.

The heat generated by the rotation and the friction created at the point where the disks come in contact with each other have adverse effects on the body and reduce their life.

Simulation of brake disks, the study of the phenomenon of heat generated, the heat transfer from the discs to each other, and their surroundings are among the most important issues discussed in the industry.

In this project, ANSYS Fluent software simulates the heat transfer process in brake disks. “Disk2” has a rotating motion with a rotational velocity of approximately 343rpm. The rotating motion of Disk 2 has been applied to it using the moving wall option.

The existing disks have the same temperature equal to 343 K. Since “Disk1” is stationary, it will cause “Disk2” to slow down and exert friction.

The Laminar model is used to solve fluid flow equations, and the energy model is also activated to calculate the temperature distribution inside the computational domain.
We designed the 3-D model with the Gambit software.
We Mesh the model with Gambit software, and the element number equals 32884.
