Скачать или смотреть Wave Solder Assembly Line

Experience our optimized wave soldering line for industrial controllers! This Short reveals the seamless process:
1️⃣ Fixture Locking: Dedicated PCB holders ensure zero-movement during assembly
2️⃣ Component Insertion: Manual placement of critical connectors
3️⃣ Wire Harness Alignment: Positioned for wave solder penetration
4️⃣ Fixture Securing: Triple-stage clamping prevents displacement

Engineered Efficiency at TJHXPCB
Our lean manufacturing system delivers:
✅ 30% faster cycle times vs industry average
✅ IPC-A-610 Class 3 compliance on all joints
✅ 0.5% defect rate through process control

Proven Methodology:

"Proper fixturing reduces solder defects by 67%" (IPC Journal). Our certified technicians combine:
🔹 ESD-safe workstations with anti-static mats
🔹 255°C±3°C wave profiling for perfect fillets
🔹 Real-time AOI validation after each station

Contact Our State-of-the-Art Facility:
https://tjhxpcb.com/contact-us-pcb-ci...

#WaveSoldering #PCBAssembly #ElectronicsManufacturing #LeanProduction #ControllerBoard #ProcessOptimization #[YourCompanyName] #IndustrialAutomation
