512x PL9823 LEDs were used to make the 8x8x8 LED RGB Cube. It consists of 8 identical segments with 8x8 LEDs. Steel wires were soldered to the LEDs for the power and data connections. The base is made of black acrylic glass. All electronic components including the power supply are located inside the base. The controller is a Wemos D1 Mini Pro Board (ESP8266 based) programmed with the ESPixelStick Firmware 4.0. A level shifter 74HCT125 is used between the controller and the first PL9823 LED. The animations were made with xLights.

Key features:

512x PL9823 LEDs (5mm diameter)
same data transfer protocol as WS2812 LEDs
LED pitch 30mm
Steel wire ~40m (0.5mm diamter, horizontal connections)
Steel wire ~13m (0.6mm diamter, vertical connections)
base dimensions 300x300x63mm
base material black acrylic glass 3mm
Controller Wemos D1 Mini Pro with ESPixelStick Firmware
SD card slot to save animations created in xLights

::::::::::::::::::::

Making a 8x8x8 RGB LED Cube
   • Making a 8x8x8 RGB LED Cube

Creating a xLights 8x8x8 LED Cube Model
   • Creating a xLights 8x8x8 LED Cube Model

Creating xLights Animations for a 8x8x8 LED Cube
   • Creating xLights Animations for a 8x8x8 LE...
