Does placing Section Views into your Civil 3D drawing cause unacceptable performance problems when working with your model? Learn how to use ProjectExplorer to turn dynamically managed Civil 3D Section Views into static AutoCAD objects in a few simple steps:

1) Create the sample line group and associated section views in Civil 3D.

2) Use ProjectExplorer to export the entire sample line group to a separate AutoCAD drawing as native AutoCAD entities. Exporting a sample line group also exports any associated section views.

3) We then delete the Sample Line Group (and associated section views) from the source Civil 3D model

4) Finally, we attach the generated AutoCAD drawing to the source Civil 3D drawing as an xref.
