The quEDU is a platform for various quantum physics experiments. It contains single photon detectors and time tagging electronics for data acquisition and analysis as well as digital interfaces to control the experiments.

The quEDU is the central unit to control connected experiments and measure their photon output. All experiment boards are connected via a data cable and multiple optical fibers to the temperature controlled APDs.

One of the experiment boards for the quEDU is the NV. The NV board includes everything for experiments on nitrogen vacancy centers. The fluorescence signal and a reference of the laser are connected via fibers to the quEDU.
