Скачать или смотреть BUTTERFLIGHT installation in 5 mins | Kalman Filter | 3.4.0

Butterflight is a fork of Betaflight that aims to bring a renewed focus on Mini Quad Flight Performance with the RaceFlight Kalman filter (info, links and shortcuts in description). This is the starter installation, read the description to set recommended settings.

-------------------------------
If you like what I do, please support me and make an offer here: https://www.paypal.me/dangeletti ...thanks!!!
-------------------------------

Butterflight: http://butterflight.co/ (domain expired?!?!)
https://github.com/ButterFlight/butte...

Butterflight Configurator:
https://github.com/ButterFlight/butte...

---------------------
RECOMMENDED SETTINGS (check Motors Temp!!!)
Make sure to set Dterm Lowpass filter to PT1
Enable Dynamic Filters | Airmode | Anti-Gravity
Disable all Notch filters
set gyro_use_32khz = ON (32Khz IMU Only)
set cpu_overclock = 192MHZ (F4 Only | 32 Khz IMU)
set gyro_stage2_filter_type = FAST_KALMAN
save
set gyro_filter_q = 400
set gyro_filter_r = 88
save
---------------------

Shortcuts:
What is BUTTERFLIGHT @ 0:19
Backup your Betaflight Configuration @ 0:40
Donwload Butterflight Configurator @ 2:05
Install Butterflight Configurator @ 2:44
Flashing Butterflight firmware @ 3:11
Butterflight Starter Filter Settings @ 4:25
Butterflight Starter CLI Settings @ 4:57
Ending @ 6:03

Different filters, filter tuning and testing | Check
Joshua Bardwell clip:    • Butterflight | BETAFLIGHT IS DEAD EVERYTHI...

STARTER SETTINGS FOR BUTTER
----------------------------------------
Here you will find helpful commands for getting your quad setup with Fast Kalman Filters, make sure you disable all of your NOTCH FILTERS:
set dterm_lowpass_type = PT1
feature AIRMODE
feature ANTI
feature DYNAMIC
set gyro_stage2_filter_type = FAST_KALMAN
SAVE
set gyro_filter_q = 400
set gyro_filter_r = 88
SAVE

For OLD AKK Smart Audio use:
set VTX_AKK_HACK = ON
----------------------------------------
