Flying laser marking machine marking metal parts‪@VISUAL‬
More View:    / @biglaser


1. The UV Laser Marking Printing Machine adopts 355nm pumped UV laser device as the light source, with small focusing laser spot, which can reduce the mechanical deformation of the material, with small processing heat effect.

2. Adopts a CCD camera auto vision positioning system, the objects to be marked can be placed anywhere on the conveyor belt working table, the CCD camera can automatically identify and marking, suitable for mass production and pipeline working.

3. The scanning area is large (175x175mm) and has no error.

4. It can mark easily without any positioning fixture, which greatly saves time and material cost.

5. Equipped with a conveyor belt for automatic batch marking, it has fast marking speed and high efficiency.

6. The marking area is as large as 175mm×175mm, which can meet the size requirements of precision devices.

7. Adopt high-quality water chiller CW-5000 with air-refrigerator function, it has good heat dissipation effect and higher efficiency.

8. Support AI, BMP, DST, DWG, DXF, DXP, LAS, PLT and other image formats.

9. The software both supports win 7 and win 10 systems.


Product name
CCD Camera Automatic Visual Positioning System Industrial UV Laser Marking Engraving Machine
Model
PEDB-UV-1
Laser type
UV
laser wave length
355nm
Marking format
175mm×175mm
Camera pixel
5 million
Camera brand
HIKVISION
Camera positioning accuracy
0.1mm
Camera software environment
Computer system is suitable for win7, win10
Dongle
1 visual positioning software dongle
Marking object placement requirements
Any angle
Power supply
220V/50-60Hz
Support graphic formats
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT,etc
Life of the laser machine
﹥100,000 hours
Cooling system
Water cooling
