F202 AC-63/0.1
General Information
Extended Product Type:F202 AC-63/0.1
Product ID:2CSF202001R2630
EAN:8012542780502
Catalog Description:F202 AC-63/0.1 Residual Current Circuit Breaker
Long Description:The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Categories
Products » Low Voltage Products and Systems » Modular DIN Rail Products » Residual Current Devices RCDs » Residual Current Devices RCDs
Previous ImageNext Image

F202 AC-63/0.1 - image 0
F202 AC-63/0.1 - image 1
F202 AC-63/0.1 - image 2
Technical
Standards:IEC/EN 61008
UL 1053
Type of Residual Current:AC type
Rated Voltage (Ur):230 V
Rated Operational Voltage:230 V
Rated Insulation Voltage (Ui):500 V
Rated Impulse Withstand Voltage (Uimp):4 kV
Rated Current (In):63 A
Rated Residual Current:100 mA
Rated Conditional Short-Circuit Current (Inc):10 kA
Rated Service Short-Circuit Breaking Capacity (Ics):1 kA
Maximum Surge Current:0.25 kA
Leakage Current Type:AC
Rated Frequency (f):50 / 60 Hz
Power Loss:at Rated Operating Conditions per Pole 3.2 W
Power Supply Connection:Arbitrary
Electrical Endurance:10000 cycle
Number of Poles:2
Operating Characteristic:Instantaneous
Mounting Type:DIN rail
Options Provided:None
Accessories Available:Yes
Connecting Capacity:Busbar 10 mm²
Rigid 25 ... 25 mm²
Flexible 25 ... 25 mm²
Rated Cross-Section:4 - Multi-Wired 0...25 mm²
1 - Solid-Core 25...25 mm²
Environmental
Ambient Temperature:-25...55 °C
Ambient Air Temperature:Operation -25...55 °C
Degree of Protection:IP2X
Pollution Degree:2
Resistance to Vibrations acc. to IEC 60068-2-6:0.1 mm or 1 g - 20 cycles at 5…150…5 Hz
Resistance to Shock acc. to IEC 60068-2-27:25g / 2 shocks / 13 ms
RoHS Status:Following EU Directive 2011/65/EU
Environmental Information:Refer to RoHS
Technical UL/CSA
Maximum Operating Voltage UL/CSA:277 V AC
Short-Circuit Current Rating (SCCR):100 mA
Dimensions
Width in Number of Modular Spacings:2
Product Net Width:0.035 m
Product Net Height:0.085 m
Product Net Depth / Length:0.069 m
Product Net Weight:0.200 kg
Built-In Depth (t2):69 mm
Container Information
Package Level 1 Units:box 1 piece
Package Level 1 Width:80 mm
Package Level 1 Height:41 mm
Package Level 1 Depth / Length:94 mm
Package Level 1 Gross Weight:0.235 kg
Package Level 1 EAN:8012542780502
Ordering
Minimum Order Quantity:1 piece
Customs Tariff Number:85363030
Country of Origin:Italy (IT)
Certificates and Declarations (Document Number)
Declaration of Conformity - CE:9AKK106713A5602
Environmental Information:Refer to RoHS
Instructions and Manuals:9AKK107991A6127
RoHS Information:2CSC423001K2702
Popular Downloads
Data Sheet, Technical Information:9AKK107991A8329
Instructions and Manuals:9AKK107991A6127
Classifications
ETIM 7:EC000003 - Residual current circuit breaker (RCCB)
ETIM 8:EC000003 - Residual current circuit breaker (RCCB)
EPLAN Catalog Tree:Electrical engineering / Protection devices / Ground fault current circuit breaker
EPLAN Function Definition:Ground fault current circuit-breaker / Ground fault current circuit breakers, 4 connection points / Ground fault current circuit breaker, two-pole 1/2 2/1 3/4 4/3
WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:Business To Consumer
CN8:85363030
