Скачать или смотреть How To Use an Automatic Tool Changer (ATC) CNC Router with Drilling Block? -Operation Instruction

The video here is an operation instruction for the automatic tool changer (ATC) cnc router machine with drill block. To learn how to use the machine, please follow the steps shown in the demo. For your information, the drill head in the demo is a 2+2 horizontal drill bank, which enables to drill holes on the four side faces of a wooden board.

For more details of the ATC CNC machine, please check it out here:
https://www.eagletec-cnc.com/atc-cnc-...

The video instruction has eight chapters:
0:00 01 Calibrate the Tool Operation
2:47 02 Switch On Vacuum Pads
3:08 03 Set the Workpiece Origin for Automatic Tool Change Spindle
4:53 04 Set the Workpiece Origin for Horizontal Drill Head / Block
12:15 05 Load File and Start Machining Operation Instruction
13:25 06 ATC Spindle Machining Demo
16:17 07 Drill Bank Working Demo
17:28 08 Completed Project Demo

Brief Configuration of this CNC Router with ATC and Drilling Head
• Max. Working Space: 2000mm x 3000mm
• Auto tool change spindle: 9KW/ISO30 tool taper/24000RPM/Air-cooled
• Drill block: horizontal 2+2
• Delta AC servo driving system with SHIMPO Planetary gearcase
• WEIHONG NC60A Industrial computer CNC system
• Vacuum pads system
• Pneumatic alignment pop-ups
• Cast iron support upright
• N.W.: 2070kgs

Focused on Building great quality automatic tool changer cnc routers & Providing best after-sales support
Jinan EagleTec Machinery Co., Ltd.
WhatsApp & WeChat & Viber: +8613065026945
Email: sales@eagletec-cnc.com
Homepage: https://www.eagletec-cnc.com

#automatictoolchangercnc #atccnc #atcrouter #atcwoodworking
