Скачать или смотреть 2-component (98:2) low-pressure system - SPRAY equipment flexibility and working principles

2-component spray application is a low-pressure system using paint guns with atomizing air. This equipment can only apply flat, continuous and interrupted, lines. The Borum machines can be supplied with one or two paint guns depending on customer needs. One spray gun can apply line widths of up to 20 cm, depending on application speed and layer thickness.

This video presents the working principles of road marking with the 2-component (98:2) paint gun equipment with atomizing air.

EASY PAINT GUN CONNECTION

For mounting the paint gun on the retainer the main things you need to do:
Fit the correct adapter for the mixer.
Connect the mixer to the mixing head.
Attach the mixing head to the bracket.
Add a paint gun on the retainer and fix it with clamps on both sides.
Attach the pneumatic connections for the paint gun.
Once you have implemented these steps, the paint gun equipment is ready for marking on the road.

SPRAYED LINE THICKNESS, MATERIAL AND MARKING SPEED

The line thickness mainly depends on the marking speed. Depending on the actual material used, as well as the operator experience, the marking speed can be up to 10 km/h.

CLEANING OF THE SPRAY GUN EQUIPMENT

The cleaning process for the paint gun is initiated from the LineMaster computer as for all Borum equipment. Because of the atomizing air pressure, there is a greater risk of losing control of the rebounding paint into a solid container, therefore Borum recommends using a waste bag covering the paint gun completely during the cleaning process.

LINEMASTER COMPUTER FOR EASY LINE MARKING

The Borum LineMaster computer is where you set and control your line markings as well as monitor the working condition of your machine. The LineMaster allows you to store up to 99 different line types and arrange these line types in up to 30 different marking programs. Feel free to find out more about Borum LineMaster computer here:    • Make your line marking job easier with the...
Moreover, we have created a playlist with instructional videos “How to use the Borum LineMaster”, which can be found here:    • How to use the Borum LineMaster

Timestamp

00:00:00 Intro
00:00:12 Line marking types
00:00:31 Atomizing air paint gun for 2-component (98:2) low-pressure system
00:00:47 Line width options using one paint gun
00:00:52 Line width options using two paint guns
00:01:04 Atomizing air paint gun connection
00:01:23 The line thickness and material
00:01:44 The 2-component (98:2) low-pressure system working principle
00:02:05 Demands for a 2-component (98:2) low-pressure system to work properly
00:02:10 The 2-component (98:2) spray equipment cleaning process
00:02:53 Sliding retainer frame "Vario retainer"
00:03:08 LineMaster computer
00:03:29 LineMaster computer special functionalities for 2-component application
