Rittal has developed a new generation of conductor connection clamps enabling panel builders and switchgear manufacturers to connect cables and wires directly to busbars.

The new push-in conductor connection clamps are available in two clamping ranges, 0.5–4 mm2 and 1.5–16 mm2, and for copper busbars, 5 and 10 mm thick in each clamping range.

The push-in conductor connection clamps enable quick and easy attachment to the busbar. The stripped end of the conductor is connected to the busbar simply by pushing them together, and the connection is held securely in place with a separate spring mechanism. The spring optimises conductivity by removing oxide layers that have formed on the busbar. And optimal contact is maintained by the integral contact block with its defined and raised contact points.

You can achieve quick and easy connections with solid, multi-wire and ultrasonic welding conductors and also fine wire conductors with wire end ferrules and twin wire end ferrules.
