Study Bookshelf Part 1 - Lower half

Cut from 1/16” (1.75mm) Craft Plywood

Piece Quant Imperial Metric Name
A 1 11 9/16 x 3 21/32” 293 x 94 mm Back
B 7 3 21/32 x 1 ¼” 94 x 33 mm Sides / Vertical dividers
D 4 3 13/32 x 1 ¼” 87 x 33 mm Cupboard top and bottom
E 2 3 5/16 x 7/32” 94 x 6 mm Vertical trim beside cupboards
F 2 3 13/32 x ⅞” 87 x 22 mm Horizontal under cupboards
G 1 4 1/16 x 3 5/16 103 x 93.5 mm Front Centre Panel *
H 2 3 7/16 X 1 ⅛” 87 X 29 mm Shelves
I 1 11 9/16 x 1 5/16” 293 x 34 mm Counter Top (lower)
J 1 11 9/16 x 1 7/16” 293 x 36 mm Counter Top (upper)
L 7 2 3/16 x 1” 54 x 25 mm Trim for Cupboards/centre panel
M 2 3 13/32 x ⅝” 87 x 16 mm Lower trim under cupboard
N 1 4” x ⅝” 103 x 16 mm Lower trim under centre panel
P 2 2 ⅝” x 3/16” 68 x 5 mm Cupboard closure trim

Cut from 3/32” (2.5mm) Craft Plywood
O 4 2 21/32 x 1 13/16” 68 x 43 mm Cupboard Doors *

*I recommend that you not cut these until you reach the assembly stage, in order to get a better fit.

Other materials:
3/32 x 3/32” Square wood dowel for trim
8 dress maker pins
2 handles for cupboards
Dollhouse baseboard
Paint

Note: There are no pieces marked C or K for this project. (I got a bit over zealous when making the cutting list, and duplicated some pieces)
