Скачать или смотреть Accessing Brocade Switch while bypassing Java

This is a step by step tutorial on how to access Brocade Switch while bypassing Java (only in newer version of Java).

Applies to:
2498-B40
2498-B24
2498-B80
The most of Brocade switches.

-------------------------------------------------------------------------------------------------------------------------

5 Steps explained:

Step 1 - Make sure that the IP address on the network that is connected to the switch are in same “scope” as the switch.

To check the IP on the switch, login in with a terminal program, I am using Tera Term (alternativ use Putty or or hyperterminal)
Com port is whatever Com port you used on PC to connect to the serial port on the switch.

Push enter, and type in the credentials for the switch.

Command to see IP is: ipaddrshow
Command to change IP is: ipaddrset

-----------------

Step 2 - Ping the Switch, to make sure, that you got a connection, open Command Prompt and use the command: ping 192.168.70.150 -t

Any IP can be used, make sure to use the only your Switch has been assigned.

-----------------

Step 3 - White the Switch’s IP
On newer version of Java, you need to whitelist the Switch to be able to access it, open Config Java, go to Security - edit site list - add your Switch´s IP, like this: http://192.168.70.150

Push okay to popups.

-----------------

Step 4 - Type the access command

Open Command Prompt, type:
Javaws
http://192.168.70.150/switchExplorer_installed.html

Push okay to popups

-----------------

Step 5 - Type in Switch login credentials

-------------------------------------------------------------------------------------------------------------------------
