Скачать или смотреть D-1946 AUTOMATIC SPRING UNITS ASSEMBLER from American Plant and Equipment

AUTOMATIC SPRING UNITS ASSEMBLER
OUTPUT (SPRINGS/8H): 24000 (DEPENDS ON THE OPRATOR)
COIL TYPE: BONNELL
COIL OUTSIDE DIAMETER (mm) (CAN BE CUSTOMIZED): 110
STEEL WIRE DIAMETER (mm): 1.9 - 2.4
SPRING HEIGHT (mm): 100-180
HELICAL WIRE DIAMETER (mm): 1.3-L5
MAX SPRING UNIT WIDTH (mm): 2000
MAX NUMBER OF JAWS: 22 (DEPENDING ON DIFFERENT SIZE)
CONTROL SYSTEM: PLC CONTROL AND OPERATOR'S PANEL
MAX WEIGHT OF WIRE ON FEECER (KGS): 1000
TOTAL POWER (KW): 4
POWER REQUIREMENTS: 380V 3 PHASES 50HZ
MACHINE WEIGHT (KGS) (ONLY FOR REF.): 935
MACHINE SIZE (LXWXH MM) (ONLY FOR REF.): 3200 X 1000 X 2100
STANDARD PACKING (ONLY FOR REF.): WOODEN PALLETS WITH PLASTIC FILMS
IT CAN ACCOUNT THE SPRING ROWS AUTOMATICALLY
IT CAN PULL OUT THE INNER-SPRING UNITS AUTOMATICALY
AFTER FINISHING THE ENACTMENT OF THE ROWS
THE SPRING ROWS CAN BE ENACTED BY THE COMPUTER
