Finally!!! I built a 6" quad that doesn't show any vibrations in the HD footage! It's so smooth, I didn't have to tune anything on the PIDs or filters level, it's completely stock. You can check out the build here: https://rotorbuilds.com/build/15884 (it's featured on the front page of rotorbuilds hehe)

Components
BrainFPV Radix as flight controller: it has a nice graphical OSD to display gyro noise and features a high-quality gyro chip
T-Motor F55A Pro ESC: according to some tests I saw, this ESC is low-noise and will provide waaayyyy enough headroom for current draw
MB Primo 2208 motors: smooth and quite cheap, these are really enjoyed by long-range enthusiasts
Runcam Racer (first version): camera with a very nice dynamic range, not going for realism here, the picture looks kinda weird but you see EVERYTHING
TBS Unify Pro MMCX: first time actually using a MMCX vTX, came in handy when assembling the quad because I could easily pop off the pigtail to remove the "canopy"
Crossfire Diversity Nano RX: the new receiver allows to use 2 antennas, thus canceling nulls in the reception pattern and also can use a backup battery to run after the main battery is ejected
35mm GPS board: I found the small 18x18mm boards tend to lose reception over time, and become quite useless after a few months. The bigger ones provide quick fixes and seem to work better
Vifly Finder 2: buzzer with its own battery so that it can still beep in case the main battery is ejected. And it's loud.

Music: IWSYS - For U

THE QUAD:
========
Frame: FridayFPV Yeti 6LR
Flight controller: BrainFPV Radix
ESCs: T-Motor F55A Pro
Motors: MB Primo 2208 2150kv
Props: Emax Avan Longrange 6x3.8x2
FPV Cam: Runcam Racer
RX: TBS Crossfire Nano Diversity RX
vTX: TBS Unify Pro HV MMCX
Antenna: VAS Ion v2
HD Camera: GoPro Hero 7 Black
Batteries: Custom Li-ion / Swaytronic / mylipo.de
GPS: RTFQ Mini Ublox M8N GPS Glonass 35x35


Other stuff:
=========
Transmitter: FrSky Taranis Q X7 + M7-R Race Gimbal
TX Module: TBS Crossfire TX w/ Diamond Antenna
Ground station: Clearview Racing 5.8GHz
Video antennas: VAS Pepperbox + TrueRC x2-AIR
Goggles: Aomway Commander V1
Bag: LowePro QuadGuard BP X2
