Electronic spirit level with two digital displays for the instantaneous measurement of inclinations and slopes.
ULTRA-PROTECT: Waterproof and dustproof in accordance with protection rating IP 67 – the spirit level is dustproof and fully washable and can even be temporarily submerged in water (water depth of up to 1 m, duration of up to 30 min).
CAL-FREE: Calibration of the electronic system is not necessary during daily use due to the high-quality sensors and advanced STABILA production process, even if the product is dropped or following temperature fluctuations. A simple calibration can still be performed for testing purposes.
Buttons are easier to clean as the membrane keypad is less sensitive.
Two digital displays that can be read easily in any conditions and illuminated at the touch of a button at two different levels – the settings of the display lighting are saved when the unit is switched off and back on again.
Acoustic guidance with two different audible signals for quick alignment of components without having to look at the spirit level – the keypad tones can be activated and deactivated and the acoustic guidance settings are saved when the unit is switched off and back on again.
The digital display rotates for measurements in the reverse position.
REF function: The reference angle function allows an angle measurement to be accepted, saved and transferred to other components.
KEY-LOCK function: Keypad lock to protect against accidental activation of the keypad.
If KEY-LOCK is activated, reference values will be saved when the unit is switched off and back on again.
HOLD function: Saves the measured value – for accurate measurements and quick transfers even in hard-to-see places.
Warning if the spirit level is tilted in the second axis.
Display modes: °, %, mm/m, in/ft – decimal and as fraction.
SENS button: Fast changeover between fine and rough adjustment in the °, % and in/ft display modes.
Long operating time of approximately 400 hours without illumination and approximately 80 hours with illumination.
At 0° and 90°, the accuracy of the electronic inclination measurement is ± 0.05°, and from 1° to 89° it is ± 0.1°.
STABILA installation technology (LOCKED VIALS) ensures long-term accuracy when measuring with spirit level vials – the measuring accuracy in normal and in reverse position is ± 0.5 mm/m.
Shock-absorbing end caps – the two-component material mix provides effective energy absorption upon impact and protects the profile.
End caps with slip stoppers – for secure positioning when marking without allowing the spirit level to slip.
Removable end caps allow exact positioning and marking right up into the corners.
Precision-milled measuring surfaces prevent any discolouration on surfaces; for example, on fair-faced brickwork.
Easy to clean thanks to the electrostatic powder coating.
Equipment: Two digital displays, two milled measuring surfaces (23 cm version: two coated measuring surfaces), spirit level bag. #shorts #beatruepro #craftsman #construction #craft #craftsman #crafting #stabila #trueproladies #buildingconstruction #tools #tooltips #dealership #drywall #levelup #leveling
