Axial Turbine CFD Simulation Using Periodic AMI | Single-Blade Approach in TCAE
Full-stage axial turbine CFD simulations are expensive, slow, and often unnecessary.

In this video, we demonstrate how **TCAE**, the advanced CFD simulation software developed by **CFD SUPPORT**, enables engineers to simulate an entire axial turbine stage using **only a single blade passage**, while still capturing the full unsteady rotor–stator interaction.

Faced with a turbine stage containing *50 stators and 55 rotors**, running brute-force CFD would mean massive meshes, long runtimes, and delayed design decisions. Instead, TCAE leverages **Periodic AMI (Arbitrary Mesh Interface) boundary conditions* to preserve the physics—without paying the cost of a full-stage model.

🔍 What TCAE delivers in this simulation:
🔹 Transient rotor–stator interaction using Periodic AMI
🔹 Accurate handling of non-matching meshes at rotating interfaces
🔹 Full unsteady flow physics with a single blade passage
🔹 Massive reduction in mesh size and computational cost

📈 Engineering & business value:
✅ Lower simulation cost through reduced mesh and compute hours
✅ Faster design feedback — results in hours instead of days
✅ Scalable performance on local machines, clusters, or HPC
✅ Reduced risk with validated, physics-based methods
✅ Higher ROI by enabling more design iterations per budget

This is *not* a push-button shortcut.
Periodic AMI requires proper setup, validation, and engineering judgment—and TCAE is built to support exactly that level of professional CFD work.

Why engineers choose TCAE for turbomachinery CFD:
✔ Open-source, transparent CFD solvers — no black boxes
✔ Proven workflows validated against benchmarks and real turbine projects
✔ Designed for complex rotating machinery and transient simulations
✔ Built by CFD experts who understand industrial constraints

📘 Full axial turbine case study:
👉 https://www.cfdsupport.com/axial-turb...

🎥 Watch the full simulation:
👉    • Unveiling Axial Turbine Stage Transient th...

If you’re still running full-stage CFD for every design iteration,
it may be time to **engineer smarter—not harder**.
