Скачать или смотреть Home Assistant - Setup RS485 on the Waveshare P4 Smart 86 Box

This is video 72 on Home Assistant and LVGL. In this video we setup the RS485 interface on the Waveshare ESP32-P4 Display Panel device to extend the control devices. We interact with them using ESPHome LVGL graphic objects. This effort builds on the previous video that describes the Waveshare ESP32-P4-86-Panel-ETH-2RO aka P4 Smart Box. The video explains how to setup ESPHome with the Modbus device and interact with it using LVGL graphic controls.

In this video,
• We demonstrate the graphics display with buttons for each Modbus relay.
• We discuss the Waveshare Modbus capabilities
• We explain the wiring between the components
• Walk through the YAML configuration

The code for this video is available at the GitHub site:
https://github.com/kwinter745321/myHA...

Background music is 7th Life by Adam MacDougall which is You Tube Licensed as not requiring an attribution.
