Скачать или смотреть JWI Us Filter "J-Press" Sidebar CGR Filter Press - 1000M32-18/28-30/20SNLC

Serial number: F07316. Caulked and gasketed recessed membrane plate design. For recovery of both solids and liquids. Filtration area: 296 sq. ft expandable to 461 sq. ft. Volume: 13 cubic feet - expandable to 20 cubic feet, cake thickness: 32mm (1.25""). Electric/hydraulic automatic closure, automatic plate shifter, plate expansion option, plc controls. Max. Feed pressure: 100psi, max. Squeeze pressure: 100psi., hydraulic clamping pressure: 3200psi, relief pressure: 3600psi. 440/480 volt, 3 phase power.
Polypropylene plates (18- expandable to 28): type: mixpack membrane l, 225 psi, center feed.
General arrangement drawing available (pdf).
*the filter press appears unused but had been stored outdoors prior to us purchasing it. The automatic shifter chain is rusty. 3" npt center feed. 2" npt 4-corner discharge.
