Features:

Rockville D12 5000w Peak/1400w RMS Class D 2 Channel Power Amplifier Pro/DJ Amp
LCD displays volume in dB per channel and operating temperature
1.5U rack space
Built in limiter protects your speakers from distortion and clipping
Bridged mode allows you to combine both channels power into one channel for use with a subwoofer
Stereo mode is perfect for (2) speakers or (4) speakers in a left and right configuration
Parallel mode gives you dual mono output signal which is perfect for monitor use when you want all sounds coming out of each speaker instead of a left/right configuration
Built in crossover switch (bypass, 80 Hz, 160 Hz) allows amp to be used with full range PA speakers, or Subwoofer(s)
Channel A & B Clipping Led Indicators
Channel A & B Separate Level Controls
Power, signal, clipping, and protection LED indicators on front of amp
Heavy duty rack mount ears with handles
Built-in variable high velocity quiet cooling fans
Maximum headroom for 4-ohm and 8-ohm Speakers
Level controls for precise setting and matching of sensitivity
Computer controlled IC protection circuitry against speaker short circuit, thermal over load, DC over load
User serviceable fuse (12A, 250V)
Frequency Response (bandwidth @ 2Vrms out, @ -3.0dB) 10 Hz – 30 Khz
THD + Noise @ 1Khz full power: <0.11%
Input Impedance: 10K Ohm Balanced
Input signal voltage: 638mV – 2.7V
Input sensitivity: 0.7v
Damping factor: ( 100Hz, 10w, 4 ohms): 43.6
Damping factor: (1Khz @ 8 ohm): >400:1
Effective damping factor (100Hz, 10w, 4 Ohms) 1.08
Output impedance at speaker terminals: 0.0918 Ohms
Frequency Response vs THD+N (worst case, across normal bandwidth 1W) 0.05%
Signal to Noise Ratio: > 100dB
SLEW RATE (input filter limited) : 40v/uS Power Requirements: 100V-240V / 50-60Hz
Weight: 9.7 lbs
Dimensions: 19.09 x 9 x 2.56 inch
Power Ratings:

RMS Power Output:

Stereo 8 Ohm: 2 x 500W
Stereo 4 Ohm: 2 x 700W
Bridged 8 Ohm: 1 x 1400W
Peak Power Output:

Stereo 4 Ohm: 2 x 2500W Max
Bridged 8 Ohm: 1 x 5000W Max
​​Terminals:

Input Terminals:

Combo jack (XLR and ¼”) A & B inputs
Output Terminals:

Banana binding post speaker output
Speak on output
XLR output to connect another amplifier or powered sub
