Скачать или смотреть F 1915Z

Source
• Light Source: 19pcs OSRAM 15W 4in1 Leds, PIXEL Control
• Led Life: 60.000 Hours
• Luminous Flux: 8000lumen, 21880lux@3m At 6°, 1600lux@3m At 65°
• Control: Remote On/Off Via DMX
• Ballast: Switching Mode Power Supply
Optical System
• Beam Angle: 6° To 65°
X/Y
• Pan: 630° (2.2.0 Sec) Or 540°(2.0 Sec), Tilt: 265° (0.85 Sec)
• 16-Bit Resolution
• Auto Repositioning
Features
• DMX Channels: 17
• Super Fast, Smooth And Silent Movement
• Pixel Control
• Nice Maping Effect With Dimming And Color Fading At The Same Time
• RGBW Four Colors Mixing To Create Vivid, Saturated And Uniform Color Effect
• Pre-Set Color Temperature At 2700K, 3200K, 4200K, 5600K And 8000K
• Zoom From 6° To 65°
• Full Range 0-100% Dimmer
• Various Strobe
• RDM Function To Change DMX Address, Display Flip, X/Y Reverse And So On
• Software Upgrade Via DMX
• Hibernation When Lost DMX For Preset Time
• Indicate Temperature Info Of Base, Arm And Lamp
• Fan Speed Auto Change According To Temperature
• Heat Pipe For Cooling
Display
• 2.4inch Super Nice LCD Display With Friendly English/ Chinese/French/Spanish Menu
• Auto Lock
• Flip
• Back-Up Communicating IC
• Pre-Set Wireless And Battery Holder
Power
• Max Power Consumption: 316W(Input), 280W(Output)
• Power Supply: Electronic Auto-Ranging
• Input Voltage Range: 100–240V, 50-60Hz
Dimension and Weight
• Fixture:344X250X445MM
• Packing: 460X400X350MM
• Net Weight: 12KG
• Gross Weight: 14KG
Rigging
• Mounting Plate With 4 ¼-Turn Locks
• 2 X Omega Brackets With ¼-Turn Quick Locks
• Safety Rope
