Скачать или смотреть semi automatic capsule filler manufacturers|YQ machinery pill filling machines

semi automatic capsule filler manufacturers|YQ machinery pill filling machines
please email via [email protected]
[email protected]
Lick us on website:
http://www.chinesepacker.com/
http://www.yqfiller.com/
Skype us by :zhang.tracy6
Call us via:+86-13262514660
whatsapp/wechat:0086-13262514660
Watch more videos
For more information,browse our Channal at    / @tracychinesepacker
▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬
▶ ︎ Subscribe to my channel and be notified of the latest equipment as soon as possible ◀ ︎
‣‣ http://bit.ly/2rGtI59
‣‣http://www.chinesepacker.com/

▶ ︎Follow me ◀ ︎
  ‣‣ Instagram ►  / packerchina
  ‣‣ wechat / whatsapp / phone no. ► +86 13262514660
  ‣‣ facebook ► https://www.facebook.com/yqmachinery/...
  ‣‣ Twitter ►  / tracyzh68943171
‣‣ Linkedin ►  / tracy-chow-57511a89
--------------------------------------------------------------------------------
Capsule feeding mechanism
This mechanism is used to take out the capsule from the hopper and insert it into the capsule feeding tube, and a leaf spring switch is arranged under the feeding tube. When the tube is driven by the sector gear and descends to the lower side, a set of capsules (7 capsules for 1# and 2#, and 6 (0#) are released as the switch hits the stopper. Then the capsule enters The feed tube rises again, and the feed tube is immediately closed by the switch operation. Through the operation of the capsule push plate, the capsule falling on the capsule comb is pushed forward to the U-shaped rotation position, and the capsule is pressed down by the capsule pressure head, and then the U Shape rotation (capsule body downwards, capsule cap upwards). When the capsule pressed down in this way leaves the capsule comb, a negative pressure air flow is provided on the lower side of the mold. Due to the air flow in the mold hole, the capsule is sucked into the mold. Like the die hole, there is a small shoulder to prevent the capsule cover from being fixed in the upper die. The capsule continues to slide down into the lower die hole under the influence of the vacuum function. Therefore, the ejection, U-turn and separation operations of the capsule are affected by this mechanism The cam, rocker and ratchet of the mechanism are driven by an independent continuously variable motor. The wheel rotates once, and the ratchet advances by one tooth, that is, the mold pushes the holes. At the same time, the cam drives the swing horizontally to make the sector gear rotate one round. Equipped with There is an automatic counting controller, when the mold is full of capsules, the mechanism will automatically stop. During the operation, it can be stopped manually. The speed of the machine is controlled by the knob on the dashboard, and there is a meter showing the speed on the dashboard. If some capsules can’t For complete separation, turn the mold 1-2 turns by hand, and assist complete separation under the vacuum adsorber. A set of molds is provided when the machine leaves the factory.

Note: 00#00#L (L is lengthened) device has 5 holes in each array. The capsule mold has 300 holes (5*60). There are 300 pins on the eject pin disk, and the corresponding capsule presser, capsule pusher, capsule comb, switch and U-shaped rotary device each have 5 arrays. Device 0 has 6 holes in each array. The capsule mould has 360 holes (6*60). There are 360 pins on the eject pin plate, and the corresponding capsule presser, capsule pusher, capsule comb, switch and U-shaped rotary device each have 6 arrays. No. 1, No. 2 and No. 3 devices have 7 holes in each array, and the capsule mold has 420 holes (7×60). The pin tray also has 420 pins, and 7 arrays are arranged on each corresponding accessory.

Technical parameter
(1) Capacity: 12500—25,000pcs/h
(2) Capacity specification:000#-5#，Long type, short and fat type
(3) Filing material：powder、granule、Pellets
(4) Voltage:380V/220V 1P/3P 4Kw
(5) Air pressure: 0.03m3/min, 0.7MPa
(6) Vacuum pump flow: 40m3/h
(7) Dimension:1.14*0.7*1.63(L*W*H)
(8) Net weight: 350Kg
