Polystyrene Foam Melter Equipment parameters:

1、The tilted feeding hopper is easy to put the Polystyrene material in，and the material won’t be pushed out during the crushing process。

The Polystyrene hot melting machine use twin shaft crushing blades, two parallel blade shafts symmetrically fixed with blade ，the blade on the two blade shafts is dislocation arrangement, and the blade of each shaft is evenly arranged in the axis of the knife with arithmetic point of view in the same direction. The first blade and the last blade of each shaft has a 90°angle.

polystyrene-foam-melter-equipment-7

2、Four blade shaft of Polystyrene Foam Melter Equipment，the rotating diameter of each shaft: φ290 mm

Two blade shaft，center diatance :250 mm

Each blade shaft has 10 blades（Assembly for 90 ° rotation）

Helical gear reducer motor power: 2.2KW×4

The rotating speed of each blade shaft: 110 r/min

polystyrene-foam-melter-equipment-4

Qinfeng Machinery is a Foam Recycling Machine manufacturer in China which can provide you with high quality of Polystyrene Foam Melter Equipment.

Application（EPS）
In recent years，Recycling of waste plastic regeneration in the ascendant. The EPS’s Wide use in the packaging industry , bulky and difficult to transport，Lead to the rapid development of the waste plastic recycling machinery. With the tenet of reducing the pollution caused by waste plastic and improving human being’s living environments, Chinafor Company organized research personnel to study abroad many times for years, made research on the markets both here and abroad and worked together closely with the domestic scientific research institutes to develop new style waste plastic recycling machines. With the difficulties of no domestic standard and reference data and focusing on the diversity and specialty of waste plastics, Chinafor developed the new style waste plastic recycling machines successfully and formed her own feature in the field of waste plastic recycling, after numerous and continuous tests and researches. In order to avoid the secondary pollution to the water and environments made by the recycling machines, Chinafor organized research personnel again to solve this technical problem and realized the upgrade of the waste plastic recycling machines with the guiding ideology of reducing secondary pollution. This new equipment is High-performance, space saving, easy to transport the finished produce. The operation is pollution-free, no – smoke and can protect the environment, and avoid the secondary pollution. Complete reuse the waste plastic and create interest.

Working principle
The EPS hot melting machine use 4 shaft crushing blades, two parallel blade shafts symmetrically fixed with blade ，the blade on the two blade shafts is dislocation arrangement, and the blade of each shaft is evenly arranged in the axis of the knife with arithmetic point of view in the same direction. The first blade and the last blade of each shaft has a 90°angle。
When the 4 shaft crushing blades are working，two parallel blade shafts with different rotation direction begin to rotate, form a wave down the grip , so that the material constant downward movement, after going through the cutting blade , and broken into smaller blocks of matter . Then the fan delivery will blow material into the bin storage, to store a certain amount, and then the material will be melted in hot melt machine .
The material will been sent by the high speed rotary screw to the heating barrel. The screw of the main machine can convey and heat the material to melt condition, then extrude them and hydraulic blade cut them to pieces for easy storage and transportation.
