In this video, I provide an overview of the Murvi Pimento SB (Single Bed) on the Ford Transit L2H2. This document covers vehicle dimensions, habitation systems, competitor USPs, and essential maintenance data for the Ford EcoBlue engine and Truma diesel heating system.

📋 Vehicle Technical Specifications (2026)
Chassis & Drivetrain:

Base Vehicle: Ford Transit 350 Leader (MWB L2).

Engine: 2.0L EcoBlue Euro 6D. 130PS (360Nm) or 170PS (405Nm) options.

Transmission: 6-speed manual or 10-speed SelectShift automatic.

Dimensions: Length: 5.53m | Width: 2.06m (mirrors folded) | Height: 2.58m.

Weights: GVW 3,500kg | Payload: approx. 600kg.

Cab Tech: 12” SYNC 4 touchscreen, 5G Modem, Lane-Keeping Aid, and Collision Mitigation.

Habitation Systems:

Electrical: 150Ah LiFePO4 (Lithium) battery; 30A DC-DC charger; 20A mains charger.

Heating: Truma Combi D 4E (4kW Diesel/1.8kW Electric).

Gas: 30L (12kg) underslung LPG tank with interior level indicator.

Water: 72L Fresh (Inboard) | 45L Waste (Insulated).

Beds: Offside single (2.14m x 0.76m); Nearside single (1.75m x 0.76m).

🔧 Engine & Heating System Maintenance
Ford 2.0L EcoBlue Diesel Engine:

Wet Timing Belt: This engine uses a "belt-in-oil" system. It requires strictly specified low-ash fully synthetic oil (e.g., Ford WSS-M2C952-A1 0W-30). Using incorrect oil leads to belt delamination and catastrophic engine failure.

Service Intervals: Ford recommends 2 years/18,000 miles, but for campervan use (heavy loads/infrequent use), an annual oil change is advised to prevent oil dilution.

DPF & EGR: Frequent short journeys prevent DPF regeneration. I recommend a 20-30 minute highway drive above 60mph every 500 miles to clear soot accumulation.

Truma Combi D 4E Diesel Heater:

Fuel Quality: Operates on Diesel (EN 590). It is sensitive to fuel quality; ensure the vehicle tank is not left low for long periods to avoid drawing sediment into the 0.1–0.4 l/h metering pump.

Decarbonization: To prevent soot buildup on the glow plug and burner, the unit should be run on "High" heat for at least 30 minutes once a month, even in summer.

Lockout Reset: If the unit fails to ignite 15 times (often due to air in the fuel line after running dry), the PCB will lock. This requires a diagnostic tool at a service center to reset; it cannot be cleared via the CP Plus/iNet X panel alone.

⚖️ Competitor Analysis & USPs
Swift Monza (Ford Transit Custom)

USP: MPV Versatility. Sub-5m length and 4 travel seats.

Contrast: Lacks the 50mm winter insulation and the internal standing height of the Pimento SB.

Westfalia Sven Hedin (MAN TGE)

USP: Fixed Rear Bed. Uses "pop-out" sides for a transverse bed.

Contrast: Prioritizes storage "garage" space. The Pimento SB offers more daytime floor space and longer single beds (2.14m).

Auto-Trail Expedition 54 (Fiat Ducato)

USP: Price. Entry-level budget conversion.

Contrast: Uses internal gas lockers and 25mm insulation. The Pimento SB frees up internal space via underslung LPG and uses 50mm SupaSoft insulation.

Devon Firefly (Ford Transit)

USP: Compact traditional layout.

Contrast: The Firefly's fixed kitchen blocks the side door. The Pimento SB’s modular sofa allows for an open-plan lounge that integrates with the outdoors.

🔍
