This is a tiny part for Cafelat Robot espresso machine. It is used to move the original pressure gauge from the robot arms (which is visible from the front) to the top of the machine, so user can see the pressure from above the machine.

You just need to get this part 3d printed and a M5 screw a little bit longer than the original one. The original one is 6.4mm of length and this part adds 5.0mm. I'm using a screw with 11.8mm of length.

I created 4 different versions of the part. One as shown in the video, so the gauge will be centered but the 3D printed part will be visible and another one that is completely hidden by the bracket, but the gauge will be off centered. Both have versions with and without the hole to store the original screw on the side of it.

Donate
If it works for you and if you want to, you can buy me a coffee! :P
https://ko-fi.com/santiagoluz

Download STL file to print it here
https://cults3d.com/en/3d-model/tool/...
https://www.printables.com/model/1301...
