Скачать или смотреть How to add a dome to a cylinder in any CAD program - 3 ways, 6 minutes

Here are three unique methods for adding a hemispherical dome shape on top of a cylinder (or any other circular face) in just about any modern, parametric CAD package (Onshape, Inventor, Solidworks, etc.). While I use Onshape, the steps will be very similar in other software.

They include revolving a sketch with a conic, lofting to a point, and using direct editing (or extrusion) in combination with parametric filleting. The tutorial shows various dome types, including G2 continuous curvature surfaces, conics with adjustable shapes, and a perfectly hemispherical, rounded dome on the cylinder.

Along the way, I give some tips for using conics, end conditions for lofts, defining planes and sketches when working with cylinders, and other tips and tricks.

Thanks for watching, and please leave any questions you have in the comments!

TUTORIAL RESOURCES
---------------------------------------------------
Final CAD model: https://cad.onshape.com/documents/439...
Measure FeatureScript (other CAD packages can name sketch variables to make parameters): https://cad.onshape.com/documents/77b...
