Do you find for a fixed/ constant output voltage circuit. Then this project is for you. In this project, we'll teach you make 2 constant output voltage circuit. These are very cheap & simple electronics project that you can make at home easily.

---------------------------------------------------------------------------------------------------

Project No - 1
Project Name - Constant output voltage circuit using NPN transistor.

Component List :
1. Transistor - BC 548
2. Resistor - 100 KΩ
3. LED - 5mm *2
4. Zener Diode - 6.2v
5. Power Source - DC (12-24) Volt
6. Soldering Iron
7. DC Meter
---------------------------------------------------------------------------------------------------

Project No - 2
Project Name - Constant output voltage circuit using shunt voltage reference

Component List :
1. Shunt Voltage Reference - TL 431
2. Resistor - 100 KΩ
22 KΩ
4.7 KΩ

3. LED - 5nn *2
4. Power Source - DC (12-24) Volt
5. Soldering Iron
6. DC Meter
