Скачать или смотреть Eurotherm EPC 3016 Configuration for PF-9070 Hot Box (Required After Reset or Replacement)

Once you’ve performed a factory reset on your Eurotherm EPC 3016, it’s critical to reconfigure your settings before enabling the heat. This video provides a step-by-step guide on how to properly set up the Quick Start, analog output, and recovery mode for the Precision Fixtures PF-9070 Hot Box.

Following these specific configuration steps is essential for the safe and efficient operation of your equipment.

⚠️ CRITICAL WARNING: Operating the EPC 3016 at its factory default values will cause permanent damage to the heating element. Please note that heater damage resulting from incorrect controller configuration is not covered under warranty. Do not enable the heat until all steps in this video are complete.

In this video, we cover:

Quick Start Configuration: Setting the control type, thermocouple, and temperature range.

Analog Output Setup: Configuring the mA.OP, OUT.HI, and OUT.LO values.

Recovery Mode: Ensuring your controller returns to the "Last" state after a power cycle.

All procedures shown in this video are documented in the PF-9070 User Manual, available at: https://www.precisionfixtures.com

Chapters

0:00 – Critical Configuration Warning
0:34 – Quick Start Setup (SEt1 & SEt2)
1:31 – Analog Output Configuration
2:46 – Recovery Mode Setup
4:09 – Final System Confirmation
