Here’s a practical guide to disassembling and upgrading an ASUS ROG Strix G513 / G517 series (G15/G17) gaming laptop — covering the internal access steps and what you can realistically upgrade.
________________________________________
🛠️ 1. Disassembly / Opening the Laptop
Important before you start
• Turn off the laptop fully.
• Disconnect the power adapter.
• Ground yourself (anti-static wrist strap recommended).________________________________________
🔌 2. Recommended Order Before Upgrading
Once the bottom cover is off:
⚡ Disconnect the Battery
Always unplug the internal battery connector before touching any components to avoid shorts and IC damage.
________________________________________
🧠 3. What You Can Upgrade
📌 a) RAM (Memory)
• Many G513 models come with user-removable SODIMM RAM modules.
• Pull the latches outward to release each stick.
• Common Upgrades:
o If originally 16 GB (2×8 GB), upgrade to 32 GB (2×16 GB) or even 64 GB (2×32 GB) — community reports show 64 GB working despite some spec sheets saying 32 GB max.
• Tip: Use DDR4 SODIMM modules that match frequency supported by your specific G513/G517 SKU.
⚠️ Some newer models solder RAM (rare in G513/G517), check visually — if there are no SODIMM slots, RAM is not user upgradeable.
________________________________________
💾 b) SSD (Storage)
• There is usually at least one M.2 NVMe SSD slot accessible once open.
• Many units have a second free M.2 slot (for adding storage) — check your specific mainboard layout.
• To install: unscrew the existing screw, slide in the new SSD at an angle, and secure it with the screw.
Upgrade tips:
• Use NVMe PCIe SSDs (Gen3 or Gen4 depending on support) — community reports confirm success with large TB sizes (2 TB+).
• Keep thermal pads or graphite pads in place for heat management.
________________________________________
🧩 What You Cannot Upgrade Easily
🚫 CPU / GPU
• CPU and GPU are soldered to the motherboard on G513/G517 (standard for slim gaming laptops). They cannot be upgraded individually.
🔁 Other Components
• Speakers, fans, Wi-Fi card, and battery are removable but are not performance upgrades (except replacing with a new one if faulty).
________________________________________
🧰 Optional Maintenance/Upgrades
🌬️ Thermal Paste / Pads
• If you’re already inside, consider replacing thermal paste on CPU/GPU and checking thermal pads — this can reduce temperatures and improve sustained performance. (Note: this is an advanced step — follow a dedicated thermal guide for your model.)
🧽 Dust Cleaning
• Use compressed air or a soft brush to clean fans and vents while open.
________________________________________
📦 Reassembly
1. Reconnect battery and any unplugged cables.
2. Align bottom cover and press until clips engage.
3. Reinstall all screws in the reverse order.
4. Power on and check BIOS → make sure RAM/SSD are detected.
________________________________________
🧍‍♂️ Safety & Warranty Notes
• Opening your laptop may affect warranty depending on local ASUS policies — check your warranty terms before proceeding.
• Handle components gently and avoid static discharge.
________________________________________
If you want exact compatible part numbers for RAM or SSD (e.g., Crucial / Kingston / Samsung) for your specific Asus ROG G513/G517 variant, just let me know your exact model number!
