Portable remote transport high-pressure forest fire pump

Product details

Stainless steel frame, easy to carry. The pump shaft is arranged horizontally to reduce vibration

The pump body is a plunger hydraulic diaphragm pump. Allows sand and gravel particles to pass, low water quality requirements, and low power loss to the engine.

The pump set can work normally when the horizontal and vertical tilt reaches 25°.

The diameter of the hose is 40mm, the burst pressure is 18MPa, the surface layer is polyester filament, the inner liner is imported rubber, and the high-pressure forest interface is connected.

The power unit equipped with the water pump is a forced air-cooled four-stroke gasoline engine.

Water pump material and structure

The water pump is an imported 3-cylinder hydraulic plunger diaphragm pump. The pump body is formed by high-strength aluminum alloy die-casting process at one time,

Ensure that the pump body will not break or screw off during high-pressure work. The connecting rod and eccentric shaft adopt aluminum-based alloy,

Nitriding treatment is carried out at the same time, and forging is used for one-time forming. The diaphragm material is hydrogen nitrile rubber,

No need to replace after tens of thousands of hours of normal work. The water pump adopts the process of oil-water separation, and the mechanical parts are all immersed in the oil tank.

The parts will not form friction, which ensures the service life of the pump. The diaphragm isolates the water from entering the mechanical compartment,

Therefore, the water pump has very low requirements for water, and sand and gravel mud can pass through.

Reducer type

The reducer adopts a planetary reducer, which is different from the large and small gear reduction of the star reducer. Too much force on the star-shaped gears is easy to lose teeth,

Thereby affecting the efficiency of the pump. The planetary reducer is a three-sided pinion gear meshing with a large gear, implementing a full range of meshing,

In any case, there will be no pulleys and tooth loss. Our planetary reducer adopts a special treatment method,

When the engine revolution exceeds 2000 revolutions, it will not weaken the power of the engine, but will help the power of the engine.

Improve the efficiency of the water pump.


Pump technical parameters

Name Technical parameters

Pump unit weight (kg) 56

Maximum flow rate (L/min) 95

Working pressure (Mpa) 12 (vertical height 1200 meters)

Maximum lift (Mpa) 15 (vertical height 1500 meters)

Maximum range (m) 24

Maximum suction range (m) 8 (with self-priming function, no need to inject water and vacuum when working)

Working suction range (m) 6.5 (with self-priming function, no need to inject water and vacuum when working)

Water inlet diameter (mm) 32

Outlet diameter (mm) 40

Dimensions (mm) Length 850*Width 520*Height 500

Engine parameters

Name Technical parameters

Engine model Bailitong

Engine type Single cylinder, forced air cooling, 4T (four stroke)

Displacement 306CC

Maximum power 34 horsepower

Start mode Hand and electric dual start

Multi-function mobile power supply to start the engine, mobile phone charging, lighting, alarm and other functions

Engine speed (rpm) 3600
