Artsen II P(C)M Double-pulse MIG/MAG Welders
Full-function Double-pulse MIG/MAG Welder for Multiple Metal Materials.

Digital Microprocessor Controlled Inverter Technology.

Synergic control of MIG/MAG/C02 process, Pulse / Double Pulse MIG/MAG.

Stable welding with stick-out length up to 30mm

Standard locking function for both front panel locking & parameters range locking.

Standard Job saving features (up to 50 Job)

Supporting SMARC for networking

Convenient for building multi-operator system

Proven record in heavy industries since 2014;

High tolerance against input voltage fluctuation (25%+/-);

Superior reliability with self-protecting design and error code display for easy maintenance;


Intermediate Wire-feeder


Light and small. with convenience for frequent mobility;

Rigid with aluminum framework;

Digital display of welding current and voltage;

Functional for current and voltage set-up;

Supporting both solid wire and flux-cored wire;

Standard gas-cool and water-cool;

Synchronization between main and intermediate wire-feeder;

Self-protecting rubber inter-connection cable;
Application & Industries
Artsen II series full-function CO2/MAG/MIG welding machines -- widely used in construction, automotive, pressure vessel, energy & power, shipbuilding, and other industries.
Features
Excellent Welding Performance

This series of products are equipped with a control process of "special energy controlled short-circuit transition", a droplet transfer control process of "pulse energy adjustment", and a synergic pulse energy control process based on varying wire feeding speeds, being suitable for carbon steel, stainless steel, and aluminum alloys and another high-quality welding, etc.



I. Push-pull Welding Torch - Outstanding Stability with Push-pull Wire-feeding

Product Features:

Capability to work with push-pull torches by major torch manufacturers with easy connection and one-button selection in the internal menu.

Welding current (wire-feeding speed) and voltage (arc-length correction) are adjustable from the push-pull torch body.

Widely used in welding aluminum for large work pieces.



II. Intermediate Wire-feeder - Mid-way Reinforcement for Ultra-Long Wire-feeding

Product Features:

Light and small, weighing only 4.3kg; robust and durable with metal structure; streamlined design for frequent mobility

Digital display for convenient checking and configuration of welding parameters.

Reaching up to 58 m working scope for solid wires of steel, including 30m by wire-feeder, 25 m by the Intermediate wire feeder, and 3 m by the torch.

Low cost in welding consumables by allowing working with an ordinary welding torch.

Widely applicable for conditions of long distance and narrow space, such as large tanks, shipbuilding, and large steel construction
