This video provides information on Coupling Decoupling Networks (CDNs) designed for conducted RF immunity testing. Rent CDNs:
https://transientspecialists.com/coll...

This video provides a more in depth overview of CDNs as an injection method for IEC 61000-4-6 testing. It includes an overview of the purpose of devices, then moves to selection criteria, and finally to the required accessories and setup.

During the video several different types of CDNs are shown including those designed for power line testing and data line testing. Time is also spent on the different categories of CDNs based on the type of line including AF, S, and the most common M type designed for power lines.

The final portion of the video is spent on both the calibration setup and test setup. This shows how the adapters and accessories are used in testing and why they are needed.

Previous Video on CDNs:
   • Coupling Decoupling Networks (CDNs) RF Imm...
Contact us directly for EMC test equipment at info@transientspecialists.com

▬ Contents of this video ▬▬▬▬▬▬▬▬▬▬
0:00 - Introduction & Opening Remarks
1:34 - CDN Applications and Rules for Selection
2:40 - CDN types and lines
3:18 - Common Coupling Decoupling Networks
5:03 - CDN Calibration Accessories
7:05 - Calibration Setup with NSG 4070
8:04 - Test Setup and Closing Remarks
