Learn how to model the iconic Julep Sofa in SolidWorks — without using Power Surfacing.
This tutorial will guide you step by step through creating organic sofa surfaces directly in SolidWorks,
using tools like Lofted Surfaces, Boundary Surfaces, Guide Curves, Mirroring, and Knitting.

Whether you’re practicing for furniture design, surface modeling, or just improving your SolidWorks skills, this video will help you build complex organic forms efficiently.

📌 What you’ll learn:
How to create complex sofa surfaces in SolidWorks
Using 3D sketches and guide curves for organic shapes
Loft and Boundary Surface techniques
Adding sewing lines, seat, and support details

timeline:
***Model the sofa back
01:54 Draw middle reference spline for sofa back
02:44 Create two new planes for section guide curves
03:16 Draw the first profile for sofa back
04:16 Draw the second profile for sofa back
05:29 Draw the third profile for sofa back
06:51 Draw the fourth profile for sofa back
07:37 Draw the first guide curve on the right plane
08:52 Draw the second guide curve on the middle plane
09:36 Draw the third guide curve
10:18 Loft the main surface
10:40 Use Boundary Surface to fill and refine the surface
11:34 Mirror the surfaces
11:57 Knit all the surfaces
12:05 Add sewing lines for sofa back
***Modeling sofa seat
14:43 Draw the profile of the seat
15:50 Extrude the body
16:19 Fillet the edges
***Modeling the sofa support
16:49 Draw the profile of the support
17:49 Extrude the body
17:58 Fillet the edges
***End
18:13 go back to modify the shape

If you found this tutorial helpful, don’t forget to subscribe to MEC 3D for more SolidWorks exercises, Power Surfacing projects, and 3D modeling tips!
