Testing with Double-8mm film made by Foma in Bohemia. Therefore we went 10km to film in Puhoi, NZ settled by immigrants from Bohemia. Double Bohemia! AND we are testing a Meopta Admira 8E camera made about 1949 in Prerov which is near Bohemia. So does that qualify as Triple-Bohemia?!

I bought the Admira for its removable lens which I assumed was a “D-Mount”. And the threading was correct for D-Mount. It accepted a C-Mount to D-Mount adapter and I tested C-Mount lenses from 16mm cameras, and also a C-Mount CCTV lens. On developing the film – shock! Horror! There was only about 20 seconds of movie and some single frame stills – all taken with the original lens. All the interesting other lenses were extremely out of focus. After some detective work I found a strange sad answer. The D-Mount flange-to-film distance is 12.29 mm. On the Admira it is much further, 17.3 mm. Why?! I can only guess that the “communist bloc” worked to different standards but a different thread would have been nice. In the “wise after the event” department, the lens is unusual for having threaded structure going a long way, about 9mm, from the flange into the camera.

The film is Fomapan 100 R designed for reversal processing. I processed as negative because I needed a quick result for planning my next “retro project” move.
I used Ilford Ilfotec LC29 at 1 + 19 dilution for 5 minutes at 20 deg C.
Here in NZ the reversal chemicals are difficult to get, especially during the Christmas/New Year southern hemisphere long summer holiday period. And we have no reversal-capable cine film labs here – the nearest is in the US. Therefore this is not a fair test of Foma film. What info we do get is:
Processing Foma R as negative is possible.
The anti-halation layer acts like a 4.5 stop neutral density filter. My homemade digitiser was able to cope with that because it works by taking a photo of each frame with a digital camera. That camera normally runs with a shutter speed of 1/60 sec. In this case it was setting speeds like 1/2 sec. Question: can commercial digitisers handle that big a variation?
The old Admira spring motor means that I do not know the shutter speed for the bracketing single frame shots. I did light metering assuming 1/20 sec and ASA 50 indicating f/2.8 as the best setting. The result is very different! My digitiser camera is automatically adjusting for negative density which is why the results for f/5.6 to f/16 look much the same. The fact that they look much the same indicates good exposure latitude.

About the Meopta Admira 8E
In my opinion this has a non-standard design that works against the interesting option of using a variety of d-mount lenses and other lenses with c-mount to d-mount adapters.
In this test we have random scratches on about half of the film
The gate and transport look like high quality engineering. However the gate wiggle effect is no better than seen in Super-8. Especially look at the opening shot with the Bohemian Museum road sign. I had the Admira on a tripod and operated with a cable release for max camera steadiness to test for gate wiggle. I am guessing that this particular Admira has had a hard life. A lot can happen in 75 years.
I have found a Double-8mm example on Youtube that appears to show good gate steadiness. Well done “simple” Kodak camera.
