Скачать или смотреть Replace the Touch Control Board | HP Chromebook 14b-ca0000 x360 Laptop PC | HP

Learn how to replace touch control board for HP Chromebook 14b-ca0000 x360 Laptop PC.

For other helpful videos go to http://hp.com/supportvideos or    / hpsupport  .
More support options for your HP device are available at http://hp.com/support.

Follow these steps to replace touch control board for HP Chromebook 14b-ca0000 x360 Laptop PC:

Before you begin: Remove the base enclosure, battery, WLAN module, display panel assembly, and LCD panel.
Removal –
Peel back the retention tape and disconnect the LCD panel cable from the sensor board.
Using minimal force, lift the locking bar up on the two touchscreen ZIF connectors.
Remove the touch control board from the adhesive and retention clips on the LCD enclosure.
Disconnect the two touchscreen ribbon cables from the touch control board and remove.
Reverse this procedure to install the touch control board.

Caution: Improperly installing or replacing parts could damage your HP device or void your warranty. Before replacing any parts, check your warranty.
