#History
The structure was built by Balfour Beatty for the British Aluminium Company and construction was finished in 1934. The supervising engineers were the firm of C S Meik and William Halcrow, now known as the Halcrow Group.
The dam was designated a Category B listed building in 1985. It was upgraded to Category A listing in 2011, following a review as part of Hydroelectric Power Thematic Survey 2010.
#Design
Water flowing over the spillway and the pipes in the centre of the dam
The dam is about 700 feet (210 m) long, and 48 metres (157 ft) high between the level of the foundations and the crest of the spillway. It is curved upstream like an arch dam with a radius of curvature of 2,000 feet (610 m), but works purely on the principle of a gravity dam.
The whole crest of the dam, except for a section in the middle that houses equipment, is a spillway broken into 29 bays by piers that support a roadway across the dam. As well as the spillway, there are six pipes embedded into the centre of the dam, controlled automatically by system of air valves. The foundations are built on granite, and the dam was built in seven sections, with copper strip and hot poured asphalt water stops in the joints.
The dam contains Loch Laggan, which has a capacity of 40,000,000 cubic metres (1.4×109 cu ft).
Water from the dam is conveyed to Loch Treig through 3 miles (4.8 km) of tunnel. From there, the waters travel through a further 15 miles (24 km) of tunnel 15 feet (4.6 metre) in diameter, before descending the hillside to a power house at Fort William through five steel pipes. The dam can be found next to the A86 road from Fort William. The catchment area of the dam was increased by an aqueduct which can be seen at the side of the road in Strath Mashie.
----------------------------------------------------------------------------------------------------------------------
História
A estrutura foi construída por Balfour Beatty para a Aluminum Company britânica e construção foi concluída em 1934. Os engenheiros que supervisionam foram a empresa de CS Meik e William Halcrow, agora conhecido como o Grupo Halcrow .
A barragem foi designada uma categoria B edifício classificado em 1985. Ele foi atualizado para Categoria A lista em 2011, após uma revisão como parte da Hidrelétrica de Pesquisa Temático de 2010.
Água que flui sobre o vertedouro e os tubos no centro do dam
A barragem é cerca de 700 pés (210 m) de comprimento, e 48 metros (157 pés) de altura entre o nível das fundações e a crista do vertedouro. Ele é curvada a montante como uma barragem de arco com um raio de curvatura de 2000 pés (610 m), mas funciona meramente no princípio de uma barragem de gravidade .
Toda a crista da barragem, com exceção de uma seção no meio que abriga equipamentos, é um vertedouro dividido em 29 compartimentos por pilares que suportam uma estrada do outro lado da barragem. Bem como o vertedouro, existem seis tubos embutidos no centro da barragem, controlada automaticamente por um sistema de válvulas de ar. As bases são construídas em granito , e a barragem foi construído em sete secções, com a tira de cobre e água vertida asfalto quente pára nas articulações.
A barragem contém Loch Laggan , que tem uma capacidade de 40.000.000 metros cúbicos (1,4 × 10 9 cu ft).
Água da barragem é transportado para Loch Treig através de 3 milhas (4,8 km) de túnel. A partir daí, as águas percorrer mais 15 milhas (24 km) do túnel 15 pés (4,6 metros) de diâmetro, antes de descer a encosta para uma casa de força em Fort William através de cinco tubos de aço. A barragem pode ser encontrada ao lado da A86 estrada de Fort William. A área de captação da barragem foi aumentada por um aqueduto , que pode ser visto no lado da estrada em Strath Mashie .
