Understanding the Pytorch Matrix Size Issue in Conv2D

If you're venturing into the world of Pytorch and deep learning, you might find yourself encountering errors when running your neural network models. One particularly common problem is the matrix size mismatch during the multiplication process, particularly when using convolutional layers such as Conv2d. In this post, we’ll explore one specific error message that you might encounter:

[[See Video to Reveal this Text or Code Snippet]]

This error often confounds new users but is resolvable with a basic understanding of Pytorch tensor dimensions and the required number of dimensions for inputs. Let’s break down the issue and the straightforward solution to get your model running smoothly again.

The Problem Explained

The error you're encountering arises due to the shape of the input tensor. Understanding what the terms in your model mean can be helpful:

mat1 and mat2 shapes: These represent the matrices that are about to be multiplied. The left matrix (generated by the output of the layers prior) has a shape of (64, 49), while the right matrix (weights of the linear layer) has a shape of (3136, 512). For matrix multiplication to occur without error, the inner dimensions must match.

Input shape: The initially fed input shape, in this case, is 1x84x84. In Pytorch, this typically refers to the 3D tensor where:

The first dimension is the number of samples (batch size),

The second and third dimensions are the height and width of the images being processed.

Understanding the Expected Tensor Shape

Flattening the Shape Correctly

In your model, the confusion arises when your convolutional layers are processed. Here’s a detailed breakdown of your network layers based on your calculations and their outputs:

First Conv2d Layer:

Input shape: 84 -> K:8, S:4 results in height of 20 (since (84 - 8) / 4 + 1 = 20).

Second Conv2d Layer:

Input from above: 20 -> K:3, S:2 results in height of 9 (since (20 - 3) / 2 + 1 = 9).

Third Conv2d Layer:

Input from above: 9 -> K:3, S:1 results in height of 7 (since (9 - 3) / 1 + 1 = 7).

Flattening:

The final output shape before the linear layer is calculated as 7 * 7 * 64 = 3136, which is the expected input size for your linear layer.

However, the error indicates a dimension mismatch before reaching the expected (3136, 512) matrix multiplication stage.

The Solution

Reshaping Input Tensors

The primary issue lies in the dimensions of your input tensor. When using convolutional networks in Pytorch, you need the input to be 4D rather than 3D. The first dimension should represent the batch size. Here’s how to correct this:

Quick Fix: If you are testing your model with a single input image, you can reshape your input tensor using the following code:

[[See Video to Reveal this Text or Code Snippet]]

Now, your input tensor will have the shape (1, 1, 84, 84)—which is compatible with Pytorch's requirements for convolutional layers. With this adjustment, you should be able to run your model without encountering the matrix size error.

Conclusion

Understanding tensor shapes is crucial in setting up neural networks in Pytorch. When you encounter matrix multiplication issues, always check to ensure that your tensors have the appropriate dimensions. The solution is often straightforward: ensure you are working with a 4D tensor for input data.

By following the outlined steps, you can overcome this common hurdle in your Pytorch journey. Remember, when in doubt—check your dimensions! Happy coding!
